ASUS Xonar Phoebus
6.7.1 Volume Control
Function Introduction
No Item Description
1 Volume Control bar
Adjust the volume level for all channels.
2 Left/ Right Channel
Lock
Click the lock/ unlock button to lock / unlock the left channel
and right channel to sync L/R channel.
3 dB Input Area
Key in a dB value in this text box to set the volume level.
4 Mute / Un-mute
Click the button to enable / disable the mute function.
5 Monitor
Click the checkbox to enable monitoring.
1
2
3
4
5
