Asus RT-N53 - Firmware Restoration Process

34
Firmware Restoration
Firmware Restoration is used on an ASUS Wireless Router that
failed during its rmware upgrading process. It uploads the
rmware that you specify. The process takes about three to four
minutes.
TolaunchtherescuemodeandusetheFirmware
Restoration utility:
1. Unplug the wireless router from the power source.
2. Hold the Reset button at the back side and simultaneously
press the power switch to power o the wireless router. Release
the Reset button when the Power LED at the front panel ashes
slowly, which indicates that the wireless router is in the rescue
mode.
3. Use the following to set up your TCP/IP settings:
IP address: 192.168.1.x
Subnet mask: 255.255.255.0
4. From your computer’s desktop, click
Start > All Programs > ASUS Utility RT-N53 Wireless
Router > Firmware Restoration.
IMPORTANT: Launch the rescue mode before using the
Firmware Restoration utility.
