WAN LED
O: No power or no physical connection.
On: Has physical connection to a wide area network (WAN).
3
5GHz LED / 2.4GHz LED
O: No 5GHz or 2.4GHz signal.
On: Wireless system is ready.
4
Power LED
O: No power.
On: Device is ready.
Flashing slow: Rescue mode
Flashing quick: WPS is processing.
5
WPS button
This button launches the WPS Wizard.
6
LAN 1 ~ 4 ports
Connect network cables into these ports to establish LAN connection.
7
WAN (Internet) port
Connect a network cable into this port to establish WAN connection.
8
Power (DC-In) port
Insert the bundled AC adapter into this port and connect your router to a power
source.
9
Power switch
Turns the power on/o.
10
Stand
Allows you to place the wireless router into an upright position.
11
Mounting hole
Allows you to mount the wireless router to the wall.
12
Reset button
This button resets or restores the system to its factory default settings.
