Rev. AX5 Draft Page 5
a
Chapter 1: General Information
Technical Data (Specifications and Outline Drawing)
TABLE 1 AdvanTag Specifications
Width 115.06 mm (4.53 inches)
Depth 41.15 mm (1.62 inches)
Height 40.39 mm (1.59 inches)
Weight TBD
Communications Serial RS-232, Ethernet, CANbus
• Protocols: ASCII, CIDRW SECS, HSMS, CAN Open
Host Protocols supported: ASCII, CIDRW SECS, HSMS
Power Reader: 24 VDC (± 10%);
500mA maximum (short range mode), 1 Amp maximum (long range
mode)
Gateway: Reader: 24 VDC (± 10%); 300mA
Environmental Operating Temperature 0°to 30° C (non-condensing)
Operating Humidity 30%- 95% (non-condensing)
Storage Temperature 0° to +55° C
Storage Humidity 5%- 90%
Mounting Mounting hardware and mounting pattern provided
