AdvanTag 9100 Technical Manual
Chapter 2: Theory of Operation
Integration of Parts
a
Integration of Parts
Mounting
GENERAL HAZARD
CAUTION
ALL MOUNTING OPERATIONS SHOULD BE PERFORMED WITH
THE POWER CORD TO THE ADVANTAG DISCONNECTED. ALSO,
BE SURE THE 24 VDC POWER CONNECTOR IS
DISCONNECTED. FAILURE TO DISCONNECT BOTH COULD
RESULT IN DAMAGE TO THE ADVANTAG AND PERSONAL
INJURY FROM MECHANICAL AND/OR ELECTRICAL HAZARDS
WITHIN THE FRONT-LOAD ENCLOSURE.
On the back of the AdvanTag reader, there are four M3 X .5 holes that can be used for
mounting. An installation kit for mounting the unit to an Asyst 300mm Front-Load is
available; contact Asyst for details.
Other details:
• Install the AdvanTag reader in a dry and clean environment.
• The AdvanTag reader should be mounted to a grounded panel.
• The AdvanTag reader should be mounted where there is easy access to the front
and rear panels and where the air vents on the top and front panel are unblocked.
• The AdvanTag reader should be located as close as possible to the physical cen-
ter of the devices that will be connected to it (the maximum recommended serial
cable length is 10 meters).
For more details, consult instructions for the appropriate installation kit.
Ports
For details on the AdvanTag reader’s ports, see “Connectors” on page 24.
