AdvanTag 9100 Technical Manual
Chapter 2: Theory of Operation
Interfaces
a
Communication
The port labeled RS232 COMM is for RS232 communication.
This is a shielded RJ45 socket. A cable which connects the Reader to a PC is available
from Asyst.
SHOCK HAZARD
CAUTION
DO NOT TOUCH THE INSIDE OF THE ANTENNA CONNECTOR.
FAILURE TO COMPLY MAY RESULT IN INJURY.
Antenna
CAUTION
ANTENNAS SHOULD ONLY BE INSTALLED BY QUALIFIED
PERSONNEL. FAILURE TO COMPLY MAY RESULT IN
MALFUNCTION OR DAMAGE TO THE UNIT AND/OR ANTENNA.
The port labeled REMOTE ANTENNA is for an external antenna. Contact Asyst for
available antennas.
This is a BNC socket; use with Asyst antennas is required.
GENERAL HAZARD
CAUTION
NEVER USE A NON-ASYST ANTENNA WITH THE ADVANTAG
9100. F
AILURE TO COMPLY WILL VOID FCC AND CE
CERTIFICATION.
Pin Signal
4
Ground
5
Tx Data
6
Rx Data
