Atag iR 12

Installation & Servicing instructions ATAG iR-Range
8
iR 12 iR 15 iR 18 iR 24 iR 32 iR 40
Flue gas / Air intake A/B mm
Gas connection mm
CH Flow connection mm
CH Return connection mm
Condensate drain connection mm 21.5
22
22
60/100
22
ATAG iR-Series
Regular
4 Dimensions
CH Flow CH Return Gas
700 150
850
220225
60
220
380
440
137
343
A
B
B
