Atag MadQ/2 Installation Manual

GB-30
CASCADE Level
The parameters in this level refer to cascaded boiler control unit in the network (e.g.
multiple boiler plants) and are only accessible in the first central control unit with bus
address 10.
PARAMETER
Designation Setting range / Setting values
Factory
setting
Individual
setting
From code
01
Switching difference 6.0...30.0 K 8 K
0123
02
Switch-on delay 0..0.60 min
0 min
0123
03
Switch off delay 0..0.60 min
0 min
0123
04
Maximum capacity for
connection
10...100%
40%
0123
05
Boiler order OFF, 1...240 h 250
0123
06
Leading boiler 1...n
1
0123
DATA BUS Level
The parameters in this level exclusively refer to the parameters that are conntected tot he
data bus.
PARAMETER
Designation Setting range / Setting values
Factory
setting
Individual
setting
From code
01
Bus address MadQ control
unit
10, 20, 30, 40, 50
10
0123
02 Bus rights RS HC
1 Janitor status
2 Tenent status
2
0123
03 Bus rights RS MC-1
3 Janitor status
4 Tenent status
2
0123
04 Bus rights RS MC-2
1 Janitor status
2 Tenent status
2
0123
RELAY TEST Level
In this level, the relays inside the control unit can be selected and their function checked
using the rotary pushbutton.
PARAMETER
Designation Setting range / Setting values
Factory
setting
Individual
setting
From code
01 Test unit
On/Off
OFF
0123
02 Test pump unmixed circuit
OFF-ON-OFF-...
OFF
0123
03 Test mixed circuit pump 1
OFF-ON-OFF-...
OFF
0123
04 Test dwk-engine
mixed circuit 1
STOP-OPEN-STOP-CLOS-STOP-
...
STOP
0123
05
Test mixed circuit pump 2
OFF-ON-OFF-...
OFF
0123
06
Test dwk-engine
mixed circuit 2
STOP-OPEN-STOP-CLOS-STOP-
...
STOP
0123
07 Test charge pump OFF-ON-OFF-...
OFF
0123
08 Test variable output1 OFF-ON-OFF-...
OFF
0123
09 Test variable output 2 OFF-ON-OFF-...
OFF
0123
