SMART ON-OFF LEVEL CONTROLLER
Enclosure : IP 40 - EN 60529
Maximum ambient temperature : 55 °C
Maximum wire length : 100 m (Controller to probe)
Main supply voltage : 230 V +/– 10 %, 50/60 Hz
115 V +/– 10 %, 50/60 Hz (Optional)
Frequency : 50/60 Hz
Maximum power consumption : 3 VA
Material : Plastic
Output : Relay contacts
Delay of Response : For all switchpoints, 3, 5, 7 and 9 sec.; 5 sec factory set
Indicators and adjustors : 1 yellow LED for signalling “Power”,
1 green LED for signalling “Pump Open”,
1 red LED for signalling “Low Alarm”,
1 red LED for signalling “High Alarm”,
1 button “TEST” for checking alarm,
1 button “RESET” for resetting the alarm,
4 push buttons for parameter settings.
Dimensions (height x depth x width) : 144 x 72 x 110 mm
Weight : 0,5 kg
Certificates
This product complies with Electromagnetic Compatibility Directive 2014 / 30 / EU and Low Voltage Directive
2014 / 35 / EU all their requirements. A fully detailed EMC and LVD assessment has been made and has the reference
This product complies with Low Voltage Directive and Electromagnetic Compatibility Directive by meeting the
standards of:
EN 61326-1:2013 : Electrical equipment for measurement, control and laboratory use. EMC requirements.
EN 61000-3-3:2013 : Electromagnetic compatibility (EMC) -- Part 3-3: Limits - Limitation of voltage changes,
voltage fluctuations and flicker in public low-voltage supply systems, for equipment with rated current
<= 16 A per phase and not subject to conditional connection
EN 61000-3-2:2014 : Electromagnetic compatibility (EMC) – Part 3-2: Limits – Limits for harmonic current
emissions (equipment input current ≤ 16 A per phase)
EN 61010-1:2010 : Safety requirements for electrical equipment for measurement, control, and laboratory
use - Part 1: General requirements
EN 60204-1:2018 : Safety of machinery - Electrical equipment of machines - Part 1: General requirements
"Steam & Control Technologies"
