ATEN CS692 User Guide

[Scroll Lock] [Scroll Lock] +
[x] [Enter]
Toggles the hotkey invocation key between [Scroll Lock] and [Ctrl].
[m] [Enter] Enables/disables mouse emulation function.
[n] [Enter] Enables/disables keyboard emulation.
[w] [Enter] Enables/disables mouse port-switching function.
[F2] [Enter] Activates Mac keyboard mapping.
[F10] [Enter] Auto detects keyboard operating platform.
[F4] [Enter] Lists current switch settings.
[F5] [Enter] Performs a USB keyboard and mouse reset.
[F6] [nn] [Enter]
Sets the keyboard language layout.
Note: nn is a two digit number that represents one of the following keyboard
language codes: US English 33; French 08; Japanese 15
[d] [Enter]
Invokes Video DynaSync, ATEN’s exclusive technology that eliminates boot-up
display problems and optimizes resolution when switching between ports.
[r] [Enter] Resets hotkeys to the default setting.
When keyboard emulation is off, the [m], [w], [F2], [F4], [F5], [F6] and [F10]hotkeys are disabled.
Support and Documentation Notice
All information, documentation, fi rmware, software utilities, and specifi cations contained in this package are subject to change without prior notifi cation
by the manufacturer. To reduce the environmental impact of our products, ATEN documentation and software can be found online at
http://www.aten.com/download/
Technical Support
www.aten.com/support
Scan for more information
http://www.aten.com/products/productItem.php?model_no=CS692
EMC Information
FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT: This equipment has been tested and found to comply with the limits
for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful

ATEN CS692 Specifications

General

Console ports	3.5mm headphone, 3.5mm mic, HDMI, USB A
Audio connections	Yes
USB connector type	USB Type-A
Number of microphone inputs	3
Number of computers controlled	2
USB 2.0 Type-A hub ports quantity	4
Power source	DC
Power consumption (typical)	0.72 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 80 %
HD type	WUXGA
Scan interval	3, 5, 10, 20 s
Video bandwidth	60 Hz
Maximum resolution	1920 x 1200 pixels
Product color	Black
Rack mounting	No
Housing material	Plastic
Master (outer) case width	395 mm
Master (outer) case height	182 mm
Master (outer) case length	405 mm
Master (outer) case weight	6130 g
Harmonized System (HS) code	85176200
Master (outer) case net weight	4090 g
Quantity per master (outer) case	10 pc(s)
Package depth	163 mm
Package width	70 mm
Package height	235 mm
Package weight	550 g

Weight and Dimensions

Depth	66.5 mm
Width	82.4 mm
Height	25.2 mm
Weight	409 g
