- 10 -
* If your console monitor has built-in speakers and supports
audio through its HD audio/video interface, separate speakers
are not needed.
No. Component Description
1 Port LEDs The LED lights on to indicate that the
computer attached to its
corresponding port is selected and
has the KVM focus.
The LED flashes to indicate that the
computer attached to its
corresponding port is being scanned
by the Auto Scan function.
The LED is off to indicate the port is
not selected.
2 Console Keyboard
Port
Your USB console keyboard plugs in
here.
3 Console Monitor Port Your HD audio/video console monitor
plugs in here.
4 Console Mouse Port Your USB console mouse plugs in
here.
5 KVM Cables The connectors at the end of these
built-in KVM cables attach to the two
HD audio/video computers/devices in
your CS692 installation. See the
diagram on page 12 for further details.
6 Console Audio Ports Your console speakers* and
microphone plug in here.
7 Port Selection
Pushbutton
Press the Port Selection Pushbutton
to toggle the KVM and Audio focus
between the two computers/devices.
