7. Appendix
65
(Continued from previous page.)
Troubleshooting
Function CL-1208 CL-1216
Environment Operating Temp.
0 - 40
o
C
Storage Temp.
-20 - 60
o
C
Humidity 0 - 80% RH
Physical
Properties
Housing Metal
Weight 15” LCD: 14.1 kg 15” LCD: 14.3 kg
17” LCD: 14.6 kg 17” LCD: 14.8 kg
L x W x H 62.6 x 48.0 x 4.4 cm (19” - 1U)
Problem Solution
There are ghost images on
the external monitor.
The distance between the external console and the
CL-1208 / CL-1216 is too great. The maximum VGA
cable distance should not exceed 20m and, in some
cases, may need to be shorter. Replace the VGA
cable with one of an appropriately short length.
cl12816_v2.book Page 65 Thursday, March 23, 2006 2:21 PM
