ATEQ F620 - Functions Menu; Available Functions for Leak Test

Sheet #601u – Functions management
Version 1.04a User guide ATEQ 6th series Page 7/26
1.3. FUNCTIONS MENUS
1.3.1. Available functions for leak test
FUNCTIONS
Name
Pr: Sequence Next Prog. > XX+
v Inter-Cyc > 0,0 S
v All Results > No / Yes
v Pass > No / Yes
v T Fail > No / Yes
v R Fail > No / Yes
v Alarm > No / Yes
v Pressure Out > No / Yes
v Reworkable > No / Yes
v Test Check > No / Yes
v
Units > SI
v USA
v Custom Leakunit >
Cal-Pa > Cal-Pa/S
> Pa > Pa/S > Pa
(Hr) > Pa (Hr)/S
v Drift Unit > 0 > 100 %
v Name
Filtering
> 0 > 650 s
v
Automatic
Connectors
> Coupling A > 0 > 650 s
v Coupling B > 0 > 650 s
Test Check Measure > 0.0
v Max Value > 0.0
v % Drift > 20
v Check time > 0.3 s
v
ATR0 > Start -Fs To +Fs
v Transient -Fs To +Fs
v % Drift 0 > 100
v Drift 0 > 200
v
ATR1 > Start > -Fs To +Fs
ATR2 Transient > -Fs To +Fs
ATR3 % Drift > 0 > 100
v Drift 0 > 200
v
Prefill Type P.Remp Standard Max Prefill
v v v Set Prefill
