QSG_G620_423.00_EN_01_2020-02-13
Default parameters of the FLOW type tests
Required times when instrument manage
automatic jigs
Time to pressurise the part under test
Time to stabilise the flow
The flow in the part must be between the
minimum and maximum reject level.
Pressure unit (bar, mbar, PSI, Pa, kPa, MPa)
Maximum level of the fill pressure
Minimum level of the fill pressure
Volume unit displayed:
— SI System: l, ml, mm
3
, cm
3
— US System: cu in, cu ft.
Test Part Volume coefficient
Flow rate unit displayed:
— SI System: cm
3
/h, cm
3
/min,cm
3
/s, ml/h, ml/min,
sccm, ml/s, l/h
— US System: in
3
/h, ft
3
/h, in
3
/min, in
3
/s, sccm.
Upper flow rate limit. Above this limit, the part is
considered as defective.
Lower flow rate limit. Under this limit, the part is
considered as defective.
Access to additional functions
Available outputs for external automatism
Function to manage automatic jigs
Starts automatically when the test part is connected
Buzzer activation configuration
Flow measurement resolution
Several automatism case depending on fail part
management
Stabilize the measurement values
Allows Minimum Flow level
Allows negative flow measurement
Give as result, the highest flow during the test
time
