Model S High Speed Sublimation printer
25
序号
名称
说明
注意事项
1
After clicking, the drop-down
menu appears, which are low
speed, medium speed and high
speed. By selecting different
parameters, the moving speed
of the head carriage is also
different.. Click jog mode to
move carriage.
The head carriage moves at
different speeds in different
options.
2
Carriage position
Display the position of the
carriage in the current state
3
Material position
Display the position of the
material in the current state
This function is not yet open.
4
Click it and move the head
carriage to the moisturizing
position. The carriage shall stay
in this position when it is in
pause or shutdown.
a. When the nozzle car is in any
position, click the “Move to
moisturizing position” option,
which will automatically move
the nozzle car to the
moisturizing position.
b. Please do not perform other
operations on the machine while
the nozzle car is moving.
5
Click it to move the head
carriage to cleaning position to
do maintenance and cleaning.
Head carriage can be moved to
this position when it is working
a. When the nozzle car is in any
position, click the “Move to
cleaning position” option to
automatically move the nozzle
car to the cleaning position.
b. Please do not perform other
operations on the machine while
the nozzle car is moving.
6
Click it to move the carriage to
initial printing position
Left board of the carriage
corresponding the original
printing position.
7
Click it to save the current
carriage position as initial
printing position
To ensure initial position add
printing pattern width which is no
more than maximum printing
width.
8
After clicking this option, the
tape will move backward.
9
After clicking this option, the
tape will move forwards
10
After clicking this option, the
nozzle holder will move to
the left.
