FIXING AND LOCKING THE DEVICE ONTO THE HANGING FRAME
Position the tilted device
on brackets.
Pivot the device upwards
and lift it to position it on
brackets.
Turn the locks on each side of the device with a screwdriver.
Installation is now complete.
1
2
3
Lock position
