 Controller Interface
►
User Interface
Nr Description
1 Menu button
2 Navigation knob (rotate knob), accept (press knob)
3 Back button
MENU
15:23
12°
19,0°
19.5
ECO
19,0°
21.5
ECO
OFF
2 heating circuit version
+ domestic hot water (DHW)
Zone 1 Zone 2
MENU
15:23
12°
19,0°
21,5
ECO
OFF
1 heating Circuit version
+ domestic hot water (DHW)
1
2
3
