Atlas Copco GA90

141
Instruction book
9096 3313 00
(1): from approx. April 30, 2009 onwards
11.8 Technical data Elektronikon® controller
General
Units 7.5 bar 8 bar 10 bar 13 bar
Refrigerant type, Full-
Feature units
R404a R404a R404a R404a
Refrigerant type, Full-
Feature units (1)
R410A R410A R410A R410A
Refrigerant quantity,
Full-Feature units
kg 2.55 1.8 1.8 1.4
Refrigerant quantity,
Full-Feature units (1)
kg 1.5 1.2 1.2 0.97
Cooling water
consumption (at water
inlet temperature below
35 °C and temperature
rise of 15 °C), water-
cooled units
l/min 103 103 103 103
Cooling water
consumption (at
water inlet
temperature between
35 and 40 °C and
temperature rise of
10 °C), water-cooled
units
l/min 154 154 154 154
Oil capacity, air-cooled
units
I 30 30 30 30
Oil capacity, water-
cooled units
l 25 25 25 25
Sound pressure level
(according to ISO
2151 (2004))
dB(A) 73 73 73 73
Parameter Value
Supply voltage
24 V AC /16 VA 50/60Hz
(+40%/-30%) 24 V DC/0.7
A
Type of protection IP54 (front)
IP54 (back)
Ambient and temperature conditions IEC60068-2
Temperature range
• Operating
• Storage
• -10
o
C ….. +60
o
C
• -30
o
C ……+70
o
C
Permissible humidity Relative humidity 90%
No condensation
Noise emission IEC61000-6-3
Noise immunity IEC61000-6-2
Mounting Cabinet door
