Atlas Copco GA90

67
Instruction book
9096 3313 00
Function
If the password option is activated, it is impossible for not authorized persons to modify any setting.
Procedure
Starting from the Main screen (see Main screen):
• Move the cursor to the action button Menu and press the enter key (2), following screen appears:
Text on figure
• Using the scroll keys (1), move the cursor to the password icon (see above, section Menu icon)
• Press the enter key (2).
• Select the modify button using the scroll keys (1) and press the enter key (2), modify the password
as required.
3.18 Programmable settings
Parameters: unloading/loading pressures for compressors without built-in refrigeration dryer
(1) Configuration
(2) Pressure Settings
(3) Mainscreen
Minimum
setting
Factory
setting
Maximum
setting
Unloading pressures
Unloading pressure (7.5 bar compressors) bar(e) 4.1 7 7.5
Unloading pressure (8 bar compressors) bar(e) 4.1 7.5 8
Unloading pressure (10 bar compressors) bar(e) 4.1 9.5 10
Unloading pressure (13 bar compressors) bar(e) 4.1 12.5 13
