Optional equipment
Reference Designation
IO2 Analog/Digital input expansion module
B2 Electronic water drain (EWD) (Full-Feature)
DPT11/12 Dual pressure transmitters
K04' Auxiliary relay, load/unload for ES100
K21 Auxiliary contact, compressor running for ES100
K25 Phase sequence relay
PDS11 Delta p switch for integrated DD filter
PDS12 Delta p switch for integrated PD filter
R1, K34 Drive motor thermistor protection, shut-down
R2, K35 Drive motor thermistor protection, warning
R96/97 Anti-condensation heaters
S10 Main power isolating switch
Y51 Water shut-off valve (water-cooled compressors)
Y5 Solenoid valve, OSCi
S4 Level switch, OSCi
PM1 potentiometer, OSCi
Reference Electric cabinet
S’ Remote pressure sensing
S1’ Remote START/Pr.STOP
S3 Emergency stop
S3’ Emergency stop remote
S4’ Remote load/unload
S6’ Remote pressure set selection
T1 Main transformer (440/110,24V)
1X0 Supply connection
1X1 Motor connection
1X2 Dryer connection
1X3 Earth connection
1X5 Connector (supply 24 VAC)
X101-136 connectors
