Instruction book
9096 3313 00
Function
If necessary, the operator can program two different setpoints. This menu is also used to select the
activesetpoint.
Procedure
Starting from the Main screen (see Main screen):
• Move the cursor to the action button Menu and press the enter key (2), following screen appears:
Text on figure
1) Configuration
(2) Pressure Settings
(3) Mainscreen
• Move the cursor to the setpoint icon (see above, section menu icon) using the scroll keys (1)
• Press the enter key (2), following screen appears:
Text on figure
(1) Pressure setting
(2) Unloading pressure 1
(3) Loading pressure 1
