Atlas Copco QAS 60 Pd - Page 108

- 108 -
v) CEE form
3p + N + PE
125 A/400 V
Unit Dimensions without undercarriage (LxWxH) 2850 x 1100 x 1635 mm 2850 x 1100 x 1635 mm
Dimensions without undercarriage, with optional 24h fuel tank (LxWxH) 2850 x 1100 x 1751 mm 2850 x 1100 x 1751 mm
Dimensions with undercarriage (adj. towbar, DIN eye) (LxWxH) 5019 x 1665 x 2201 mm 5019 x 1665 x 2201 mm
Dimensions with undercarriage (fixed towbar, DIN eye) (LxWxH) 4780 x 1665 x 2201 mm 4780 x 1665 x 2201 mm
Weight net mass - without undercarriage 1535 kg 1535 kg
Weight wet mass - without undercarriage 1756 kg 1756 kg
Weight net mass - without undercarriage, with optional 24h fuel tank 1601 kg 1601 kg
Weight wet mass - without undercarriage, with optional 24h fuel tank 2128 kg 2128 kg
Weight net mass - with undercarriage 1930 kg 1930 kg
Weight wet mass - with undercarriage 2151 kg 2151 kg
