Instruction Manual
1) At reference conditions, if applicable, and at normal shaft speed,
unless otherwise stated.
2) Data Measured according to Tolerance
Free air delivery ISO 1217 ed.3 +/- 5% 25 l/s <FAD<250 l/s
1996 annex D +/- 4% 250 l/s <FAD
The international standard ISO 1217 corresponds to following national standards:
- British BSI 1571 part 1
- German DIN 1945 Part 1
- Swedish SS-ISO 1217
- American ANSI PTC9
3) Air required for engine and compressor cooling, combustion and for compression.
4) with filter change
5) Coldstart: compressor oil DTE22 instead of DTE25
6) For Hose Reel application: maximum ambient temperature 30°C
Compressor type
XAS 67 DD -
XAS 130 DD7
XAS 67 DDG -
XAS 130 DD7G/
DDG IT
XATS 67 DD -
XATS 125 DD7
XAS 77 DD -
XAS 150 DD7
XAS 97 DD -
XAS 185 DD7
XAS 97 DDG -
XAS 185 DD7G/
DDG IT
Designation Unit Value Value Value Value Value Value
Design data
Compressor
1. Number of compression stages 1 1 1 1 11
Engine
1. Make Deutz Deutz Deutz Deutz Deutz Deutz
2. Type D2011L03 D2011L03 D2011L03 D2011L03 D2011L03 D2011L03
3. Coolant Oil Oil Oil Oil Oil Oil
4.Number of cylinders 333333
5. Bore
mm 94 94 94 94 94 94
6. Stroke
mm 112 112 112 112 112 112
7. Swept volume
l 2.332 2.332 2.332 2.332 2.332 2.332
8. Output according to ISO 9249 G at
normal shaft speed
kW 32.5363631.53636
- Load factor
% 50 50 50 50 50 50
9. Capacity of oil sump:
- Initial fill
l 8.5 8.5 8.5 8.5 8.5 8.5
- Refill (max.)
4)
l 666666
10.
Capacity of cooling system l ------
Unit
1. Capacity of compressor oil system l 888888
2. Net capacity of air receiver
l 16.7 16.7 16.7 16.7 16.7 16.7
3. Capacity of fuel tank
l 80 80 80 80 80 80
4. Air volume at inlet grating
(approx.)
3)
m
3
/s 0.85 0.85 0.85 0.93 1.2 0.81
