PV-10PX andPV-10HPX Parts List 46
PV-10PX / PV-10HPX
Item Part# Description
Qty.
Note
PV-10PX PV-10HPX
31 217028 Offside lock cover 1 1
32 217034B Offside column 1 1
33 209051B Adapter 1.5” 4 4
34 209052B Adapter 2.5” 4 4
35 209053B Adapter 5” 4 4
36 209059 Anchor bolt 12 12
37 620065 Shim 10 10
38 217114A Rubber pad assy. 4 4
38A 420138 Socket bolt 4 4
38B 209134 Rubber Pad 4 4
38C 680030B Rubber Pad frame 4 4
39 217036 Bottom pulley 2 2
40 217037 Bottom pin 2 2
41 209038 Hex Bolt 6 6
42 217168 Arm pin 4 4
42A 520023 Snap ring 4 4
43 209039 Lock washer 18 18
44 209022 Washer 18 18
45 206049 Moon gear 4 4
46 217322 Outer arm for left front 1 1
47 206048 Socket bolt 12 12
48 206032 Snap clip 4 4
49 211016 Fitting ring 1 1
50 206036 Roll pin 4 4
51 217044 Arm lock 4 4
52 217045 Spring 4 4
53 217046A Left arm lock bar 2 2
54 217046 Right arm lock bar 2 2
55 209019 Screw 12 12
56 217053 Protective Rubber 2 2
57 209009 Cup head bolt 26 26
58 217054 Carriage plastic cover 2 2
59 217197 Carriage 2 2
60 217188 Slider block 16 16
61 217056 Cylinder 2 2
62
217171 Wire cable 1 0
217172 Wire cable 0 1
63 206025A Foam Cushion 1 1
64 206129 Limit bar 1 1
