Atlas PV-10PX User Manual

Installation Steps 9
PV-10PX / PV-10HPX
2. Move the lift aside with a fork lift or hoist, and open the outer packing carefully.
Fig. 7
3. Remove the top connecting assembly and parts box.
Fig. 8
4. Lift the upper column with a fork lift or hoist and loosen the bolts on the
upper package stand. Remove the upper column and take out the parts in the
bottom column.
Fig. 9
Shipment
Parts list
Serial No.
Top Connecting Assembly
Parts box
