Figure 30-5. ATmega48A: Active Supply Current vs. V
CC
(Internal RC Oscillator, 8MHz)
30.1.2 Idle Supply Current
Figure 30-6. ATmega48A: Idle Supply Current vs. Low Frequency (0.1-1.0MHz)
85 °C
25 °C
-40 °C
0
1
2
3
4
5
1.5 2 2.5 3 3.5 4 4.5 5 5.5
V
CC
(V)
I
CC
(mA)
5.5 V
5.0 V
4.5 V
4.0 V
3.3 V
2.7 V
1.8 V
0
0.02
0.04
0.06
0.08
0.1
0.12
0.14
0.16
0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1
Frequency (MHz)
I
CC
(mA)
