Figure 30-7. ATmega48A: Idle Supply Current vs. Frequency (1-20MHz)
Figure 30-8. ATmega48A: Idle Supply Current vs. V
CC
(Internal RC Oscillator, 128kHz)
5.5 V
5.0 V
4.5 V
0
0.5
1
1.5
2
2.5
3
02468 10 12 14 16 18 20
Frequency (MHz)
I
CC
(mA)
1.8 V
2.7 V
3.3 V
4.0 V
85 °C
25 °C
-40 °C
0
0.007
0.014
0.021
0.028
0.035
0.042
1.5 2 2.5 3 3.5 4 4.5 5 5.5
V
CC
(V)
I
CC
(mA)
