Figure 30-37. ATmega48A: Calibrated 8MHz RC Oscillator Frequency vs. V
CC
Figure 30-38. ATmega48A: Calibrated 8MHz RC Oscillator Frequency vs. Temperature
85 °C
25 °C
-40 °C
7.6
7.7
7.8
7.9
8
8.1
8.2
1.5 2 2.5 3 3.5 4 4.5 5 5.5
V
CC
(V)
F
RC
(MHz)
5.5 V
3.3 V
1.8 V
7.6
7.7
7.8
7.9
8
8.1
8.2
-50 -40 -30 -20 -10 0 10 20 30 40 50 60 70 8090
Temperature (°C)
F
RC
(MHz)
