30.2.4 Power-down Supply Current
Figure 30-58. ATmega48PA: Power-Down Supply Current vs. V
CC
(Watchdog Timer Disabled)
Figure 30-59. ATmega48PA: Power-Down Supply Current vs. V
CC
(Watchdog Timer Enabled)
85 °C
25 °C
-40 °C
0
0.2
0.4
0.6
0.8
1
1.2
1.5 2 2.5 3 3.5 4 4.5 5 5.5
V
CC
(V)
I
CC
(uA)
85 °C
25 °C
-40 °C
0
2
4
6
8
1.5 2 2.5 3 3.5 4 4.5 5 5.5
V
CC
(V)
I
CC
(uA)
