363
8271D–AVR–05/11
ATmega48A/PA/88A/PA/168A/PA/328/P
30.2.3 ATmega48PA: Supply Current of IO Modules
The tables and formulas below can be used to calculate the additional current consumption for
the different I/O modules in Active and Idle mode. The enabling or disabling of the I/O modules
are controlled by the Power Reduction Register. See ”Power Reduction Register” on page 43 for
details.
It is possible to calculate the typical current consumption based on the numbers from Table 30-4
on page 363 for other V
CC
and frequency settings than listed in Table 30-3 on page 363.
30.2.3.1 Example
Calculate the expected current consumption in idle mode with TIMER1, ADC, and SPI enabled
at V
CC
= 2.0V and F = 1MHz. From Table 30-4 on page 363, third column, we see that we need
to add 11.2% for the TIMER1, 22.1% for the ADC, and 17.6% for the SPI module. Reading from
Figure 30-53 on page 360, we find that the idle current consumption is ~0.028 mA at V
CC
= 2.0V
and F = 1MHz. The total current consumption in idle mode with TIMER1, ADC, and SPI enabled,
gives:
Table 30-3. ATmega48PA: Additional Current Consumption for the different I/O modules
(absolute values)
PRR bit Typical numbers
V
CC
= 2V, F = 1MHz V
CC
= 3V, F = 4MHz V
CC
= 5V, F = 8MHz
PRUSART0 2.9uA 20.7uA 97.4uA
PRTWI 6.0uA 44.8uA 219.7uA
PRTIM2 5.0uA 34.5uA 141.3uA
PRTIM1 3.6uA 24.4uA 107.7uA
PRTIM0 1.4uA 9.5uA 38.4uA
PRSPI 5.0uA 38.0uA 190.4uA
PRADC 6.1uA 47.4uA 244.7uA
Table 30-4. ATmega48PA: Additional Current Consumption (percentage) in Active and Idle
mode
PRR bit
Additional Current consumption
compared to Active with external
clock (see Figure 30-48 on page
358 and Figure 30-49 on page
358)
Additional Current consumption
compared to Idle with external
clock (see Figure 30-53 on page
360 and Figure 30-54 on page
361)
PRUSART0 1.8% 11.4%
PRTWI 3.9% 20.6%
PRTIM2 2.9% 15.7%
PRTIM1 2.1% 11.2%
PRTIM0 0.8% 4.2%
PRSPI 3.3% 17.6%
PRADC 4.2% 22.1%
ICCtotal 0.028 mA (1 + 0.112 + 0.221 + 0.176)⋅ 0.042 mA≈≈
