ATtiny15L
46
I/O Port B
All AVR ports have true Read-modify-write functionality when used as general digital I/O ports. This means that the direc-
tion of one port pin can be changed without unintentionally changing the direction of any other pin with the SBI and CBI
instructions. The same applies for changing drive value (if configured as output) or enabling/disabling of pull-up resistors (if
configured as input).
Port B is a 6-bit bi-directional I/O port.
Three data memory address locations are allocated for Port B, one each for the Data Register – PORTB, $18, Data Direc-
tion Register – DDRB, $17 and the Port B Input Pins – PINB, $16. The Port B Input Pins address is read only, while the
Data Register and the Data Direction Register are read/write.
Ports PB5..0 have special functions as described in the section “Pin Descriptions” on page 4. If PB5 is not configured as
external reset, it is input with no pull-up, or an open-drain output. All I/O pins have individually selectable pull-ups, which
can be overridden with pull-up disable.
The Port B output buffers on PB0 to PB4 can sink 20mA and thus drive LED displays directly. PB5 can sink 12 mA. When
pins PB0 to PB4 are used as inputs and are externally pulled low, they will source current (I
IL
) if the internal pullups are
activated.
Alternative functions of the Port B
In ATtiny15L four Port B pins, PB2, PB3, PB4, and PB5 have alternative functions as inputs for the ADC. If some Port B
pins are configured as outputs, it is essential that these do not switch when a conversion is in progress. This might corrupt
the result of the conversion. During power-down mode and ADC noise reduction mode, the Schmitt triggers of the digital
inputs are disconnected on these pins. This allows an analog input voltage close to V
CC
/2 to be present during power-down
without causing excessive power consumption. The Port B pins with alternate functions are shown in Table 1 on page 4.
When the pins PB4..0 are used for the alternate function, the DDRB and PORTB registers have to be set according to the
alternate function description. When PB5 is used as external reset pin, the values in the corresponding DDRB and PORTB
bit are ignored.
The Port B Data Register – PORTB
The Port B Data Direction Register – DDRB
The Port B Input Pins Address – PINB
The Port B Input Pins address – PINB – is not a register, and this address enables access to the physical value on each
Port B pin. When reading PORTB, the PORTB Data Latch is read, and when reading PINB, the logical values present on
the pins are read.
Bit 76543210
$18 - - - PORTB4 PORTB3 PORTB2 PORTB1 PORTB0 PORTB
Read/Write R R R R/W R/WS R/W R/W R/W
Initial value 0 0 0 0 0 0 0 0
Bit 76543210
$17 - - DDB5 DDB4 DDB3 DDB2 DDB1 DDB0 DDRB
Read/Write R R R/W R/W R/W R/W R/W R/W
Initial value 0 0 0 0 0 0 0 0
Bit 76543210
$16 - - PINB5 PINB4 PINB3 PINB2 PINB1 PINB0 PINB
Read/Write RRRRRRRR
Initial value 0 0 N/A N/A N/A N/A N/A N/A
