4.2 Equipment List
The CM board is built around an ARM
®
Cortex
®
-A5-based microcontroller (BGA 324 package) with external memory and
Gigabit Ethernet PHYsical layer transceiver.
4.2.1 Devices
4.2.2 Interface Connection
SODIMM200 card edge interface
4.2.3 Configuration Items
One jumper for SPI DataFlash chip select connection
Table 4-2. CPU Module Specifications
Characteristic Specifications
PCB CPU Module (10 layers)
Dimensions in mm:
(L x W x H) 67.60 *(40 to 47) * 5 max
Processor SAMA5D31, SAMA5D33, SAMA5D34, SAMA5D35 and SAMA5D36 (324-ball BGA package)
Clock speed 12 MHz crystal
32.768 kHz
Memory 2 x DDR2 2 Gb 16 Meg x 16 x 8 banks
1 x SLC NAND Flash 2/4Gb 8-bit data
1 x NOR 128 Mb 16-bit data
On-board I/O Ports One Serial EEPROM SPI
One 1-Wire EEPROM DS2431
One user-powered red LED and one user blue LED
One gigabit Ethernet PHY
Connector SODIMM200
Board supply voltage 3.3V from SODIMM200 connector
On-board power regulation
Temperature:
- operating
- storage
0°C to +60°C
-40°C to +85°C
Relative humidity 0 to 90% (non condensing)
RoHS status Compliant
Board Identification
Silkscreen top
SAMA5D31-CM
SAMA5D33-CM
SAMA5D34-CM
SAMA5D35-CM
SAMA5D36-CM
