76
SAMA5D3x-EK User Guide [USER GUIDE]
11180B–ATARM–29-Oct-13
5.4 PIO Usage and Interface Connectors Details
5.4.1 Power Supply
Figure 5-24. Power Supply Connector J4
Table 5-4. Power Supply Connector J4 Signal Description
Pin Mnemonic Signal Description
1 Center +5V
2GND
3 Floating
