Atmel SAMA5D3 EK Series User Manual

2
SAMA5D3x-EK User Guide [USER GUIDE]
11180B–ATARM–29-Oct-13
Contents
Important: Unpack and assemble the kit carefully, following the assembly guide provided in the box.
 Boards
 One SAMA5D3 main board (MB)
 One of the five available CPU module (CM) boards
 SAMA5D31-CM
 SAMA5D33-CM
 SAMA5D34-CM
 SAMA5D35-CM
 SAMA5D36-CM
 One optional Display Module (DM) board (5"_WVGA_R-DM), available for all SAMA5D3x evaluation kits
that feature an LCD interface: SAMA5D31, SAMA5D33, SAMA5D34, SAMA5D36
 Power supply
 One universal input AC/DC power supply with US, Europe and UK plug adapters
 One 3V lithium battery type CR1225
 Cables
 One micro A/B-type USB cable
 One RJ45 crossed cable
 A welcome letter
Related Items
 Atmel SAMA5D3 Series Datasheet

Atmel SAMA5D3 EK Series Specifications
