SAMA5D3x-EK User Guide [USER GUIDE]
11180B–ATARM–29-Oct-13
4.4 Embest/Flextronics Schematics
This SAMA5D3x-EK CM board manufactured by Embest/Flextronics is available in Revision D and Revision E. In this
section, schematics are provided for both revisions.
4.4.1 CPU Module Revision D Schematics
This section contains the following schematics:
 Block diagram
 SAMA5D3x power
 SAMA5D3x NOR and NAND
 4 Gb DDR2
 SAMA5D3x DataFlash, 1-wire, LED
 Ethernet
 200-pin SODIMM
