SAMA5D3x-EK User Guide [USER GUIDE]
11180B–ATARM–29-Oct-13
5.5 Main Board Schematics
This section contains the following schematics:
 Block diagram
 General information
 SODIMM
 Power supply
 HSMCI
 CAN & ZigBee & USART1
 Audio
 Smart DAA
 HDMI
 ETH
 USB interface
 Miscellaneous
 LCD and ISI
 On-board JTAG interface
