35
SAMA5D3x-EK User Guide [USER GUIDE]
11180B–ATARM–29-Oct-13
4.4.2 CPU Module Revision E Schematics
This section contains the following schematics:
 Main sheet
 SODIMM 200
 Power supply
 CPU power supply
 DDR2 interface
 FI: NAND, NOR, Serial, I2C, 1-wire
 Ethernet
 USB, JTAG, LEDs
 Bus interface
