LCDDAT2 PA2 69 70 PA3 LCDDAT3
––
––
GND
–
71 72 PA4 LCDDAT4
––
––
LCDDAT5 PA5 73 74 PA6 LCDDAT6
––
––
LCDDAT7 PA7 75 76 PA8 LCDDAT8
––
––
LCDDAT9 PA9 77 78 PA10 LCDDAT10
––
––
LCDDAT11 PA11 79 80 GND
––
––
LCDDAT12 PA12 81 82 PA13 LCDDAT13
––
––
LCDDAT14 PA14 83 84 PA15 LCDDAT15
––
–
ISI_D0 LCDDAT16 PA16 85 86 PA17 LCDDAT17 ISI_D1
–
ISI_D2 TWD2 LCDDAT18 PA18 87 88 PA19 LCDDAT19 TWCK2 ISI_D3
––
GND
–
89 90 PA20 LCDDAT20 PWMH0 ISI_D4
ISI_D5 PWML0 LCDDAT21 PA21 91 92 PA22 LCDDAT22 PWMH1 ISI_D6
ISI_D7 PWML1 LCDDAT23 PA23 93 94 PA24 LCDPWM
––
––
LCDDISP PA25 95 96 PA26 LCDVSYNC
––
––
LCDHSYNC PA27 97 98 GND
––
––
LCDPCK PA28 99 100 PA29 LCDDEN
––
ISI_VSYNC URXD1 TWD0 PA30 101 102 PA31 TWCK0 UTXD1 ISI_HSYNC
VDDANA 103 104 VDDANA
–
PCK0 AD10 PD30 105 106 PD31 AD11 PCK1
–
––
GND
–
107 108 PD29 AD9
––
––
AD8 PD28 109 110 PD27 AD7
––
––
AD6 PD26 111 112 PD25 AD5
––
––
AD4 PD24 113 114 PD23 AD3
––
––
AD2 PD22 115 116 GND
––
––
AD0 PD20 117 118 PD21 AD1
––
––
TXD0 PD18 119 120 PD19 ADTRG
––
PWMFI3 SPI0_NPCS3 RTS0 PD16 121 122 PD17 RXD0 PIO
–
CANRX0 SPI0_NPCS1 SCK0 PD14 123 124 PD15 CTS0 SPI0_NPCS2 CANTX0
––
GND
–
125 126 PD13 SPI0_NPCS0
––
––
SPI0_SPCK PD12 127 128 PD11 SPI0_MOSI
––
––
SPI0_MISO PD10 129 130 PD9 MCI0_CK
––
PIO PWML3 MCI0_DA7 PD8 131 132 PD7 MCI0_DA6 TCLK0 PWMH3
PWML2 TIOB0 MCI0_DA5 PD6 133 134 GND
––
PWMH2 TIOA0 MCI0_DA4 PD5 135 136 PD4 MCI0_DA3
––
––
MCI0_DA2 PD3 137 138 PD2 MCI0_DA1
––
––
MCI0_DA0 PD1 139 140 PD0 MCI0_CDA
––
VDDIOP1 141 142 VDDIOP1
Table 5-27. SODIMM200 CON1 Signal Descriptions
