01
05
06
02
04
03
Remove the appliance
covers (Figure 2).
Connect the Pressure Relief
Device (PRD) to the unit (Fig1)
Note: IMPORTANT – do not
discard this step. A PRD
must be installed.
Connect the water inlet hose to the entry point of the heater (left side
inlet), and connect the outlet hose to the water outlet. Use a hose that
can withstand a minimum pressure of 4 bars. Using any other type of
hose will cause damage (Figure 5).
Residential plumbing systems with unstable pressure or pressure
above 5 bar require the application of a pressure stabilizer valve, set
to 4 – 5 bars.
Do not install the water heater with water connections facing
upward or to the side (Figure 6)
Mount unit to wall with 4 screws at the
marked points (Figure 4)
The appliance must be mounted
horizontally, with water inlets and outlets
at the bottom (Figure 5)
1. Mount ground plate
to wall.
2. Pull wires through.
3. Cut out hole in back
of unit (Right/Left
back) and pass wires
through
(Figure 3)
Assembly Instructions
3
