TROUBLESHOOTING
10
41
ALERT/ISSUE
POSSIBLE CAUSE SOLUTION
RED ERROR
VOLTAGE ISSUE
ORANGE ERROR
VOLTAGE ISSUE
YELLOW ERROR
VOLTAGE ISSUE
GREEN ERROR
VOLTAGE ISSUE
VOLTAGE ISSUE
RED BOOSTER
VOLTAGE ISSUE
ORANGE BOOSTER
VOLTAGE ISSUE
YELLOW BOOSTER
VOLTAGE ISSUE
GREEN BOOSTER
Components on one output line
exceed maximum watts.
Check the installed components on output line with issue to see if
usage exceeds maximum watts. The spec sheet of each component
will list watts used. If an output line exceeds maximum, setup
may require use of power booster(s) and proper distribution of
components.
Wiring on output line has an
electrical short.
Check the components and wiring installed on the indicated output
line. Somewhere in the wiring, an electrical short is occurring which
generally happens when the positive and negative sides of low voltage
wire are making contact with each other. This sometimes happens if a
staple goes through a wire. The physical wiring issue must be fixed.
RED ERROR
NOT DETECTED
ORANGE ERROR
NOT DETECTED
GREEN ERROR
NOT DETECTED
Components are not wired
correctly.
Check wiring and connection points for all fans and lights on the
output indicated.
Settings are not aligned with
components installed.
It the output indicated is not being used, setting needs to indicate this
by selecting (N) on the screen.
ORANGE = Internal Fans (ACE)
GREEN = Lights
Go to the settings menu and check selection for each output line to
align setting to actual components being installed.
