ATOMSTACK A20 Pro User Manual

Shield（red part）
Air guide hood
（white part）
S t e p 5
Place the cutting pad under the engraved/cut object,
The cutting pad should be placed to coincide as much as possible with
the working area.
Cutting Pad
The laser power of this machine is very high, if you need to cut wood and other flammable
materials with a power of more than 70%, please ensure someone is watching the machine in case
of the flammable materials catches fire.
A lot of smoke is generated in engraving or cutting wood and other
objects, be aware of cleaning the air guide hood and anti-skid cover,
since there may be a lot of dust accumulation on it, especially working
with more than 50% of the laser power.
Remove the shield if you could, or turn on the air assit while machine
working, all of which would significantly reduce dust accumulation.

ATOMSTACK A20 Pro Specifications

General

Laser Power	20W
Laser Wavelength	455nm
Control Software	LaserGRBL, LightBurn
Laser Electric Power	90W
Engraving Accuracy	0.01mm
Laser Protective Cover	Yes
Input Voltage	AC 110-220V
Supported File Formats	NC, BMP, JPG, PNG, DXF
Material Capability	Wood, Bamboo, Cardboard, Plastic, Leather
Data Transmission Method	USB
Engraving Area	400mm x 400mm
Focusing Method	Fixed Focus
Output Voltage	DC 24V
