Additional information CPA12 - 24 - 36
TECHNICAL SPECIFICATIONS
CPA12 CPA24 CPA36
Rated output
(at T.H.D. 1.0%, 1kHz)
120W 240W 360W
Gain control -12dB ~ 0dB
Input sensitivity
(at balanced line)
1.0 ± 0.1Vrms / 10Kohm
High-pass filter
(at 400Hz)
-3dB
Frequency response +1.5 / -3dB at 70Hz ~ 18kHZ
S/N Ratio Better than 90dB
T.H.D. at ½ rated output, 1 kHz Less than 1.0%
4Ω / 22V 4Ω / 31V 4Ω / 38V
41Ω / 70V 21Ω / 70V 13.6Ω / 70V
Output voltage and impedance
83Ω / 100V 41Ω / 100V 27.8Ω / 100V
Cooling Fan
Operating temperature/Humidity 0° ~ 40°C at 95% at non-condensing
Dimensions (WxHxD) 48.2 x 8.8 x 34 cm
Net. Weight 11.65 kg 13.87 kg 15.16 kg
Power consumption at 1/8 power 185W 361W 525W
Power requirement AC100V ~ 240V, 50/60Hz and/or DC24V
