CONTENTS
Safety Information ...................v
Safety Symbols .....................vi
Disclaimer........................vi
Description........................1
Scope of This Manual..................1
Introduction ......................1
DC Voltage Measurements ...............2
Resistance Measurements ...............3
DC Voltage Outputs...................5
Digital Input ......................6
Digital Output ......................7
Program Control Outputs ..............8
Auxiliary Output Ports ................10
Installation .......................11
Mounting .......................11
Primary Power Considerations ...........11
Checking or Changing Power Line Voltage ....11
Fuse Information ...................13
Changing Fusing Arrangement ...........14
Power Switch .....................15
Proper Environment .................15
Connecting the APIB Interface............16
Operation ........................17
Panel ..........................17
Volts/Ohms Measurements .............18
DC Output 1 and 2 On/Off..............21
DC Output 1 and 2 Value ..............21
Digital Input and Output ..............22
Program Control, Gate Delay............25
Auxiliary Outputs ..................26
Specifications .....................29
DCX-127 Multifunction Module User’s Guide Page iii
