Specifications
DCX-127 Multifunction Module User’s Guide Page 29
DC VOLTS MEASUREMENT RELATED
Accuracy
1
6 rdg/sec 25 rdg/sec
200 mV range 0.05% + 0.03 mV 0.05% + 0.1 mV
2 V range 0.05% + 0.1 mV 0.05%+1mV
20 V range 0.05%+1mV 0.05% + 10 mV
200 V range 0.05% + 10 mV 0.05% + 100 mV
500 V range 0.05% + 100 mV 0.05%+1V
Resolution
200 mV--200 V ranges 0.005% of range 0.025% of range
500 V range 100 mV 500 mV
Input Resistance 10 MW , ± 1% (all ranges)
Common Mode
Rejection
>120 dB, at dc and 50 Hz to 20 kHz
Common Mode Range 500 Vpeak
Normal Mode Rejection >60 dB, 50 Hz to 60 HZ
1 Valid from + 15°C to +30°C, <80% RH, for 1 year. Derate linearly to
2 times indicated values at + 5°C and +40°C.
1 Valid from + 15°C to +30°C, <80% RH, for 1 year. Derate linearly to
2 times indicated values at + 5°C and +40°C.
