Specifications
Page 30 DCX-127 Multifunction Module User’s Guide
OHMS MEASUREMENT RELATED
Accuracy
1,
2
6 rdg/sec 25 rdg/sec
200W range 0.05% + 0.04 W 0.05% + 0.1 W
2kW range 0.05% + 0.2 W 0.05% + 1 W
20 kW range 0.05% + 1 W 0.05% + 10 W
200 kW range 0.05% + 10 W 0.05% + 100 W
2MW range
3
0.15% + 100 W 0.15%+1kW
Resolution 0.005% of range 0.025% of range
Open Circuit Voltage <6 Vdc
DC OUTPUT RELATED
Range ± 10.500 V (bipolar output)
Resolution 20 µV (20 bits equivalent)
Accuracy
1,
4
±(0.05% + 0.2 mV), absolute
±40 µV, relative to best fit line
Maximum Output Current 20 mA source; 10 mA sink
Residual Noise < 10 µV rms,10 Hz to 80 kHz bw
Output Floating Characteristics
Electronically balanced to allow low
output (-) terminal to float up to
2 Vpk. Common mode rejection is
typically >54 dB (500:1).
2 With both 2-wire or 4-wire configurations. When using 4-wire configuration,
lead resistance must be £ 1.5 W.
3 Full scale on the 2 MW range is 2.50 MW.
4 Load current must be £ 1 mA for specified accuracy. Output resistance is
typically <0.1 W.
2 With both 2-wire or 4-wire configurations. When using 4-wire configuration,
lead resistance must be £ 1.5 W.
3 Full scale on the 2 MW range is 2.50 MW.
4 Load current must be £ 1 mA for specified accuracy. Output resistance is
typically <0.1 W.
