Audio Technica AT-LP120-USB Installation And Operation

10
Specications
†
Turntable Specifications
Type 3-Speed, fully manual operation
Motor DC motor
Drive method Direct drive
Speeds 33-1/3 RPM, 45 RPM, 78 RPM
Pitch variation +/- 10% or +/- 20%
Turntable platter Die-cast aluminum
Starting torque >1.6 kgf.cm
Braking system Electronic brake
Wow and flutter < 0.2% WRMS (33 RPM)
Signal-to-noise ratio > 50 dB
Output level
Pre-amp “PHONO” 2.5 mV nominal at 1 kHz, 5 cm/sec
Pre-amp “LINE” 150 mV nominal at 1 kHz, 5 cm/sec
Phono pre-amp gain 36 dB nominal, RIAA equalized
USB function
A/D, D/A 16 bit 44.1 kHz or 48 kHz USB selectable
Computer interface USB 1.1 Compliant Windows XP, Vista or
MAC OSX
Power supply 115/230V AC, 60/50 Hz
requirements
Power consumption 11W
Dimensions 450.0 mm (17.72") W x 352.0 mm
(13.86") D x 157.0 mm (6.1") H
Weight 10.7 kg (23.5 lbs.)
Accessories included Headshell/cartridge (AT95E); AC line cord;
dual RCA (female) to 3.5 mm (
1
/
8
") mini-
plug (male) stereo adapter cable; dual
RCA (female) to 3.5 mm (
1
/
8
") mini-plug
(female) stereo adapter cable; 45 RPM
adapter; USB cable; recording software
Cartridge Specifications (AT95E)
Frequency response 20 – 20,000 Hz
Channel separation >20 dB at 1 kHz
Vertical tracking force 1.5 – 2.5 grams
Stylus construction Bonded round shank
Output 3.5 mV at 1 kHz, 5 cm/sec
Channel balance 2.0 dB
Stylus shape 0.4 x 0.7 mil elliptical
Cantilever Aluminum
Mount Half-inch
Replacement stylus ATN95E
†
Specications are subject to change without notice.

Audio Technica AT-LP120-USB Specifications

General

Interface	USB, Analog
Signal-to-Noise Ratio (SNR)	50 dB
AC adapter frequency	50/60 Hz
AC adapter input voltage	115 - 230 V
Power consumption (typical)	11 W

Weight and Dimensions

Weight	10700 g
Product dimensions (WxHxD)	450 x 352 x 157 mm
