Audio Technica AT-LP120-USB Installation And Operation

3
Installing Audacity software for MAC OSX and above
Cables
Red to Red
White to White
5. Turn your computer on.
6. Insert the included Audacity CD in your Mac’s CD drive. Open the CD icon on your
desktop. Drag the installation folder for Audacity to your applications folder.
When the files have been copied, eject the CD.
USB cable (included)
RCA
USB
AC
Included adapter cable (RCA
to 3.5 mm stereo male)
Typical connection for:
Speakers with 3.5 mm
stereo input
(using adapter cable)
1. Before installing software, assemble the turntable, following directions in the
included Owners Manual.
2. Plug the AC cord on your turntable into an AC power outlet.
3. Next, use the included USB cable to connect the turntable to your Mac’s USB port.
4. If you have external self-powered speakers, make certain they are plugged into
your computer’s audio input or into the line-out RCA plugs of the USB turntable, and
that the Phono/Line switch on your turntable is switched to Line. (Audacity offers
a software play-through feature that allows you to listen to the album through your
computer while recording, even if you don’t have external speakers.) If your computer
has a headphone output, you can choose to monitor your recording with headphones.
NOTE: On the AT-LP240-USB and the AT-LP1240-USB, the RCA cables are not
permanently attached to the turntable; they plug into the RCA jacks on the back of
the turntable. See the AT-LP240-USB and AT-LP1240-USB owner’s manuals for cable
connection instructions.
Typical connection for: Speakers with
RCA inputs

Audio Technica AT-LP120-USB Specifications

General

Interface	USB, Analog
Signal-to-Noise Ratio (SNR)	50 dB
AC adapter frequency	50/60 Hz
AC adapter input voltage	115 - 230 V
Power consumption (typical)	11 W

Weight and Dimensions

Weight	10700 g
Product dimensions (WxHxD)	450 x 352 x 157 mm
