6. To re-install the dust cover, guide the dust cover hinges into the two hinge receptacles located at the back of the turntable
housing.
Setting the Pre-amp (Phono/Line) Switch
For increased flexibility of use, this turntable has an internal stereo phono pre-amplifier. The Pre-amp Selector (Phono/Line) Switch is located
on the back of the turntable. If the stereo system you are using has a PHONO input, set the Pre-amp Selector Switch to the “PHONO”
position. If your stereo system does not have a PHONO input, set the Pre-amp Selector Switch to the “LINE” position and connect the
turntable’s output cables to the AUX or other high-level input on your stereo system (described later)
Connecting to Stereo System
1. Connect the red RCA-type pin-plug to the right channel input and the white RCA-type pin-plug to the left channel input of
your stereo system .
2. With the tone arm still fastened to the tone arm rest, slowly turn the turntable platter clockwise ten times, to make certain
the automatic mechanism is fully cycled.
3. Remove the vinyl tie that holds the tone arm on its rest.
4. Connect the power cord plug to an AC outlet.
Connecting to Computers or Audio Devices with 3.5 mm Input
The AT-LP60 connects without adapters to devices equipped with RCA connectors. For maximum flexibility, we have included two adapter
cables to fit other popular audio inputs. The first of these adapter cables–dual RCA to stereo 3.5 mm mini-plug (male)–is designed to fit most
popular computer* audio inputs. It may also be used to connect the turntable’s RCA output to other equipment,
including:
a stereo/boombox* equipped with a 3.5 mm mini input
powered speakers* equipped with a 3.5 mm mini input
a mixer* or PA system* equipped with a 3.5 mm mini jack
The second included adapter cable–dual RCA to stereo 3.5 mm miniplug (female)–permits connection of the turntable output to amplified
speakers* or similar devices. The 3.5 mm stereo mini-jack on the cable adapter accepts stereo mini-plugs. To use either adapter cable,
connect the turntable’s red and white RCAtype plugs to the cable adapter’s RCA-type jacks.
* When using either cable adapter, always set the AT-LP60 turntable’s Pre-amp Selector Switch to the “LINE” position.
(Switch is located on the back of the turntable.)
NOTE: If connection is desired to a mono amplifier/speaker, make certain to use a stereo-to-mono adapter, available from your dealer or an
electronic parts store. Inserting a mono plug in the stereo jack will disable one of the stereo channels. Other adapter cable configurations will
be available from dealers and parts stores for connecting to devices needing different terminations.
Operation
Automatic Operation
1. Remove the stylus guard from the stylus assembly.
2. Put a record on the turntable. If needed, use the 45 RPM adapter.
