Audio Technica AT-LPW30BK User Manual

8
Playing a record
Before playing a record
1. Remove the cartridge’s protector.
• If the tonearm is fixed to the tonearm rest, remove the clamp.
2. Place the record on the turntable mat so that the center hole
aligns with the spindle.
• If playing a 45 RPM record, attach the 45 RPM adapter (see the diagram to
the right below).
Playing a record
Lower the volume of the amplifier, speakers, etc., sufficiently.
1. Turn the power switch on.
2. Use the control knob to select the speed.
• Select “33” for a 33-⁄ RPM record, or “45” for a 45 RPM record.
• The platter begins spinning.
3. Raise the tonearm by lifting the tonearm lift control lever to the
UP position.
4. Position the tonearm over the desired location (groove) on the record.
5. Lower the tonearm by moving the tonearm lift control lever to the
DOWN position. The tonearm descends slowly onto the record
and play begins.
• Alternatively, you can skip steps 2 to 4, and use your fingers to lift the
headshell, move the tonearm over the desired location on the record, and
then place the headshell down to begin playing the record.
• Do not subject the product to strong impact during playback.
Pausing the record
1. After lowering the volume of the amplifier, speakers, etc.,
sufficiently, lift the tonearm with the tonearm lift control lever.
Stopping the record
1. Lower the volume of the amplifier, speakers, etc., sufficiently.
2. Lift the tonearm lift control lever, return the tonearm to the
tonearm rest, and fix it with the clamp.
3. Turn the control knob to the "STOP" position.
• The platter slows down and rotation stops.
4. Remove the record after the platter has come to a complete stop.
• If the turntable mat gets dirty, it can easily scratch the record, so remove
the turntable mat periodically and wipe off any dust.
• To prevent the record from becoming scratched or warped, remove it
after use.
• Do not use a platter other than the one provided.
• This product is not intended for DJs. Do not touch the record or the
turntable mat while the record is playing.
45-RPM
adapter
At 33-1/3 RPM At 45 RPM
Record
Turntable mat
Protector

Audio Technica AT-LPW30BK Specifications

General

Type	Belt-drive audio turntable
Operation	Manual
Output level	200 mV
Product color	Black
Wow & flutter	0.15 %
Nominal speeds	33 1/3, 45 RPM
Stylus pressure	3 g
Platter material	Aluminum
Pick-up arm length	223.6 mm
Signal-to-Noise Ratio (SNR)	60 dB
AC adapter frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
Overhang	18.6 mm
Tracking angle	2 °
Quantity	1
45 rpm adapter	Yes
Package depth	488 mm
Package width	418 mm
Package height	192 mm
Package weight	5964 g
Country of origin	China

Weight and Dimensions

Depth	340 mm
Width	420 mm
Height	1169 mm
Weight	5000 g
