Page #31 background imageLoading...
Page #31 background image
30
Specifications
ATW-T3201 / ATW-T3201a
RF output power High: 30 mW, Low: 10 mW (switchable), at 50 ohms
Spurious emissions Following federal and national regulations
Input connection Four pin locking connector
1
4
2
3
Pin 1: GND
Pin 3: MIC INPUT
Pin 2: INST INPUT
Pin 4: DC BIAS +5 V
High-pass (low-freq. roll-off) 125 Hz, 12 dB/octave
Batteries Two 1.5V AA, not included
Battery life*
High: 8.0 hours (alkaline)
High: 9.0 hours (Ni-MH 1,900 mAh)
Low: 9.0 hours (alkaline)
Low: 9.5 hours (Ni-MH 1,900 mAh)
Dimensions 64 mm (2.52") × 82 mm (3.22") × 23 mm (0.91") (W × D × H)
Weight (without batteries) 102 g (3.6 oz)
Operating temperature range -5 ºC to +45 ºC (23 º F to 113 ºF)
* Depending on battery type, usage and environmental conditions.
ATW-T3202 / ATW-T3202a
RF output power High: 30 mW, Low: 10 mW (switchable), at 50 ohms
Spurious emissions Following federal and national regulations
Microphone capsule Interchangable industry standard thread
High-pass (low-freq. roll-off) 150 Hz, 6dB/octave
Batteries Two 1.5V AA, not included
Battery life*
High: 8.0 hours (alkaline)
High: 9.0 hours (Ni-MH)
Low: 9.0 hours (alkaline)
Low: 9.5 hours (Ni-MH)
Dimensions
ATW-T3202 / ATW-T3202a (without capsule): 193 mm (7.60") long, 37 mm (1.46") maximum diameter
ATW-T3202/C510, ATW-T3202a/C510: 265 mm (10.43") long, 54 mm (2.13") maximum diameter
ATW-T3202/C710, ATW-T3202a/C710: 271 mm (10.67") long, 50 mm (1.97") maximum diameter
Weight (without batteries)
ATW-T3202 / ATW-T3202a (without capsule): 200 g (7.1 oz)
ATW-T3202/C510, ATW-T3202a/C510: 330 g (11.6 oz)
ATW-T3202/C710, ATW-T3202a/C710: 314 g (11.1 oz)
Operating temperature range -5 ºC to +45 ºC (23 º F to 113 ºF)
Included accessories AT8456a Quiet-Flex™ stand clamp (5/8"-27 male to 3/8"-16 female threaded screw adapter)
* Depending on battery type, usage and environmental conditions.
For product improvement, the product is subject to modification without notice.
